what is going on guys is time to do the Caddy bkd swap , someone bought the old engine so now is the time for the build series.
I was hoping it was a plug and play engine swap but I ended up having to do a few wire changes.
There's a few different fuse box's so if yours is the same as mine hopefully this video is of some use. I'll include a full pin out of what I done to get the BKD running in the caddy 2k.
#caddyconversion #caddy2k #buildseries
Glow plug wiring swap using caddy fuse box
Red with white 6mm T26/1 to T40/4
Black with Yellow 0.5mm T26/3 to T40/26
Black with Red 1.0mm T26/6 to T40/21
Black with Grey 0.35mm T26/4 to T40/6
