Feniex One Controller Functions and Programing

Here we show how to wire and program the Feniex One! https://swatara.square.site/product/feniex-one/734?cs=true&cst=custom check out our other Feniex Quad products at http://swatara.square.site/quad-series Description Feniex One The Feniex One is the world’s first autonomous controller. Feniex Industries now brings the officer, the fleet manager and the installer a brand new product of incredible performance. The Feniex One champions functionality, ease of use, and streamlined installation. The next evolution in smart controllers goes beyond traditional standards with innovations that bridge the gap of automation. Transformative technology. The Feniex One. FEATURES All in one autonomous controller with integrated siren and light control Powered by an ARM A9 Quad Core Processor providing speed & reliability Built-in 200 Watt dual-tone siren with radio rebroadcast & audio commands Integrated 3-position programmable rugged pursuit slide switch 16 programmable push buttons with 5-color programmability Anti-glare MilSpec LCD touchscreen with brightness control LCD screen displays live vehicle health alerts and power settings 3 additional programmable push buttons built into LCD touchscreen Controller encased and protected in a rugged aluminum housing Feniex software system for user configurability and programming Integrated wifi connectivity for live field software & firmware updates Connects to Feniex Web, Feniex’s live fleet health monitoring system 32 programmable outputs rated at 5 amps each with short circuit protection Relay encased in rugged aluminum housing regulating heat disbursement Integrated GPS timing chip for vehicle to vehicle global pattern sync 8 programmable inputs with optional 12v+ or 12v- programmability 8 programmable Quad serial outputs for streamlined installation 15-foot plug-in microphone included for PA functionality Optional OBD2 plug-in module for vehicle auto triggers Easy field serviceability with plug-&-play connectivity SPECIFICATIONS Product Part Number: F-0121 Max Current Draw: 60 Amps Operating Current Draw: 1 Amp Controller Cable Length: 15 Feet Relay Plug-in Cables: 1 Foot Programmable Buttons: x19 Programmable Outputs: x32 Programmable Inputs: x8 Fusion Data Link Ports: x2 Quad Serial Ports: x8 Siren Power: 200 Watts Dual Tone Input Voltage: 10-18 Volts DC Dim of Controller: 7.3” x 1.13” x 3.13” Dim of Relay Box: 8” x 6.25” x 2.44” 2 Year Manufacturer Warranty Made in the USA: Austin, TX
