I Built the mini powerful 500W UPS!!! DIY

Special thanks to JLCMC for sponsoring! JLCMC offers nearly 2000,000 products of mechanical components. Get $123 discount coupons: https://jlcmc.com/?from=TI26 JLCMC has recently upgraded its new-user registration benefits, increasing the value of the welcome coupon package to $123 in discount coupons. 500W DIY UPS with 12V LiFePO4 Battery | Acrylic Case | Dual Output | Smart Charging In this video, I built a 500W DIY UPS / inverter system using a 12V LiFePO4 battery with a clear acrylic enclosure. This project is designed as a compact, efficient, and reliable backup power solution for home and workshop use. This UPS features two AC output sockets, a 12V battery level indicator, an AC voltmeter and ammeter display, a cooling fan, and a main power switch for safe and stable operation. The ampere meter coil was not working correctly, so I separated and modified the current sensing coil to fix the measurement issue. MAIN FEATURES 500W inverter / UPS output 12V LiFePO4 battery system with 30A 4S LiFePO4 BMS Two AC output sockets Battery level indicator for 12V system AC voltmeter and ammeter display Cooling fan for thermal management Main power switch Clear acrylic enclosure for a clean and modern design CHARGING SYSTEM For charging, I used a 4S lithium battery charger module that supports: USB Type-C input 5V input 12V DC input I also added a 12V input socket and a 5V regulator to safely power the 4S charger module. This makes the UPS flexible and easy to charge from multiple power sources. BATTERY AND PROTECTION Battery: 12V LiFePO4 (4S configuration) Protection: 30A 4S LiFePO4 BMS The BMS handles overcharge, over-discharge, over-current, and voltage protection. ENCLOSURE AND MECHANICAL PARTS The enclosure is made from clear acrylic, giving the project a clean and professional appearance while keeping the internal parts visible. For screws, mechanical parts, and components, I used JLCMC. If you are building a higher-power inverter or UPS, JLCMC aluminum enclosures are also a good option due to their better heat dissipation compared to plastic cases. SPONSOR Special thanks to JLCMC for sponsoring this project. JLCMC offers nearly 2,000,000 mechanical components for DIY and engineering projects. Get $123 discount coupons for new users: https://jlcmc.com/?from=TI26 THIS VIDEO IS USEFUL IF YOU ARE SEARCHING FOR DIY UPS 500W LiFePO4 inverter 12V battery backup system Homemade UPS DIY inverter with BMS Acrylic case electronics project Power backup system for home DIY UPS, 500W inverter, LiFePO4 battery, 12V inverter, homemade UPS, DIY inverter, 4S BMS, battery backup, power backup system, electronics project, inverter build, UPS build, DIY power system
