As a Certified SolidWorks Expert, I would like to provide an in-depth understanding of SolidWorks 2020. The sixth video tutorial is about creating a Ratchet.
The objective of this tutorial are as follows:
- to use dynamic mirror tool (real-time mirroring)
- to use mid plane condition
- to add draft angle
- to rename features in the FeatureManager Design Tree
- to use offset tool
- to use the offset from surface condtion
- to add sketch relations
- to add a new view orientation
Don't forget to hit LIKE button, SHARE the video, and SUBSCRIBE for more tutorial videos.
#SolidWorks2020 #SolidWorks #DynamicMirroring #SolidWorksBasics #BasicPartModeling #CSWE #CSWP #CSWA
Kindly comment down below if you have comments and/or suggestions. Thanks
-Solid Design
